JXF綜(zong)合(he)配(pei)電(dian)箱(xiang)(xiang)(xiang)由(you)箱(xiang)(xiang)(xiang)體(ti)、塑料(liao)外(wai)(wai)殼式斷路(lu)器、小型斷路(lu)器、聚氯乙(yi)烯絕緣導線(xian)(xian)(xian)、銅母排(pai)(pai)(pai)、N排(pai)(pai)(pai)、PE排(pai)(pai)(pai)、絕緣子、電(dian)能表等(deng)(deng)組成；箱(xiang)(xiang)(xiang)體(ti)分(fen)為(wei)(wei)(wei)左(zuo)右(you)(you)兩部分(fen)，左(zuo)部分(fen)為(wei)(wei)(wei)進線(xian)(xian)(xian)室，右(you)(you)部分(fen)為(wei)(wei)(wei)出(chu)(chu)線(xian)(xian)(xian)室和計量室。箱(xiang)(xiang)(xiang)體(ti)采用冷(leng)軋鋼板焊接而(er)成，操作面能遮(zhe)擋所有帶電(dian)部件,操作面的防護等(deng)(deng)級為(wei)(wei)(wei)IP20C。外(wai)(wai)殼防護等(deng)(deng)級為(wei)(wei)(wei)IP30。主開(kai)(kai)關(guan)出(chu)(chu)線(xian)(xian)(xian)排(pai)(pai)(pai)位于主塑料(liao)外(wai)(wai)殼式斷路(lu)器出(chu)(chu)線(xian)(xian)(xian)端下方(fang)，分(fen)支斷路(lu)器的線(xian)(xian)(xian)全部接好后(hou)分(fen)相并入主開(kai)(kai)關(guan)出(chu)(chu)線(xian)(xian)(xian)排(pai)(pai)(pai)。主開(kai)(kai)關(guan)進出(chu)(chu)線(xian)(xian)(xian)排(pai)(pai)(pai)、N排(pai)(pai)(pai)、PE排(pai)(pai)(pai)表面鍍錫處理。主開(kai)(kai)關(guan)進線(xian)(xian)(xian)方(fang)式為(wei)(wei)(wei)上進線(xian)(xian)(xian)。
|
